2. Daily Maintenance
6
• Avoid storing consumable items in locations accessible to children.
Wiper Cleaning
The wiper wipes off ink adhering to the print head nozzle surface. Continuing to use the product when it is
dirty may result in damage to the nozzle surface due to dried ink and dust on the dirty wiper, leading in turn
to print defects (e.g., nozzle clogging, deflection).
• Be careful to avoid leaving fragments from the cleaning stick behind when cleaning. These
fragments will increase the risk of print defects (e.g., nozzle clogging, deflection).
1
In LOCAL mode, select [MENU] > [Maintenance], then press the [ENTER] key.
• The Maintenance menu is displayed.
2
Select [Station] > [Carriage Out] > [Move To Platen Right End], then press the [ENTER] key.
• The carriage moves on the platen.
3
Open the front cover.
4
Pull out the wiper.
• Hold the lug at the rear of the wiper, then tilt forward to pull out the wiper.
Lug
To Next Page
