15
Warning
NOTE: Minarik strongly recommends the installation of
an emergency stop switch. The switch contacts should be
rated at a minimum of 125 volts and 200% of maximum
motor current.
m
Line starting and stopping
When AC line voltage is applied to the drive, the motor
accelerates to the set speed. When AC line voltage is removed,
the motor coasts to a stop. Line starting and stopping (applying
and removing AC line voltage) is recommended for stopping in
emergency situations only. It is not recommended for frequent
starting and stopping.
MM21111A
Set the POWER switch to OFF. The motor will coast to a stop.
Alternatively, dynamic braking may be used (Figure 4, page 17).
MM21211A
Set the RUN/BRAKE switch to BRAKE. The motor will quickly
stop using dynamic braking. To coast the motor to a stop, set the
POWER switch to OFF without first setting the RUN/BRAKE
switch to BRAKE.
Operation
Starting and Stopping Methods
