Figure 6. Typical IR COMP and TORQUE Settings
(settings may vary by application)
TORQUEIR COMP
TORQUEIR COMP
1/20 HP
1800 RPM
90 VDC
0.56A CURR
TORQUEIR COMP
1/15 HP
1800 RPM
90 VDC
0.75A CURR
1/8 HP
1800 RPM
90 VDC
1.3A CURR
