MINATO 1866 - Caution; External View and Names of Parts; External View

3
CAUTION
When operating the Model 1866, the following items must
be observed:
o Power supply
(1) The power supply to be used must be capable of
generating 90 to 110 percents (50 or 60H z) of the
rated voltage of your coLTntry.
(2) The 1866 must be separated from equipment wh ich
is likely to produce noises (copier, cooler or eraser,
etc.).
(3) Do not turn on and off power w ith any P-ROM
inserted in its
socket; otherwise, the P-ROM may be
damaged.
o Storage and environmenta l cond i tions
(1) The 1866 is provided with vents at the rear to preve nt
any temperatu re rise; do not cover any vents and do
not put the 1866 in any place wit h few ventilations.
(2) Do not expose the 1866 to direct sunshine and heat.
(3)
Do not put the 1866 in any extremely wet or dusty
place.
(4) The
1866 is composed of elect roni c precision parts.
Do not subject them to any shock.
(5) Do not use the 1866 wi th any foreign materials
(water, liquids, metal
s, etc.) contained; ot h erw is e
they may be damaged.
o Troubles
If any troub l es (e.g., abnormal odor or over-heat) are
found, disconn ect the power cord plug and contact the
representative
or MINATO ELEC T RONICS INC.
4
EXTERNAL VIEW AND NAMES OF PARTS
4-1 External View
4
Power Switch . Fuse Ho lder and Power Connector
I
ROM Socket
~I
~
~
~ ' r
~ / -;:::::>
/~::»
/'
For Serial I/O Connector
I
Dispaly
'<---- Key Switch
