16 Probes and Biopsy
Operator’s Manual 16 - 29
b. Hold the probe by one hand, select the proper needle-guided bracket, and hold it with the
other hand. Match the groove of the bracket with the tab of the probe. Amount the bracket
onto the probe.
c. Hold the probe by one hand, select proper needle-guided bracket, and hold it with the
other hand, and align the grooves of the needle-guided bracket with the tabs of the probe,
then push the needle-guided bracket forward, making the grooves of the needle-guided
bracket to match with the tabs of the probe. Set the needle-guided bracket at the desired
position, turn tightly the knob of fixing needle-guided bracket to fix the needle-guided
bracket.
d. Check manually to confirm the needle-guided bracket is securely installed on the probe.
2. Install the guiding block:
a. Select a proper guiding block and push it into the groove above the support of needle-
guided bracket, then turn tightly the knob of fixing the guiding block to fix the guiding
block on the support of needle-guided bracket.
b. Insert a biopsy needle with the same specification as that of the guiding block into the
hole of the guiding block
3. Remove the needle-guided bracket:
