A Barcode Reader

Operator’s Manual A - 7

A.2 2D Barcode Reader (Take DS4308 as an

example)

The 2-D barcode reader supports hand-held operation mode.

Hand-held mode: press the trigger to decode.

A.2.1 Overview

1 LED • Green: A barcode was successfully decoded.

• Red: A data transmission error or reader malfunction occurred.

2 Scan window Scan the barcode.

3 Trigger Press to decode.

Default Chapter3
