2 - 22 Operator’s Manual
2 System Overview
Controls on the touch screen
Tap and hold the screen to enter control editing stage.
You can not enter the stage from cine review mode or when there is a dialog box on the screen.
2.14.3 Voice Recognition
Currently, only wireless microphone devices can be inserted to the system for inputting vocal
commands.
Figure 2-9 Voice Control Panel
12. Language button /
13. Arrow button Tap to add an arrow comment to the image.
14. Library Tap to pop up and select the library.
No. Item Description
Function Operations
Adding a control Tap to select a button to add and tap [Confirm].
Add a user-defined
control
In comment and body mark editing status, tap and then tap [Custom] to
bring out the dialog box for adding user-defined controls. Enter the control
name and tap [Confirm].
Delete a control Tap of the target control and tap [Confirm] to delete.
Change the control
position
Tap and drag the control to the desired position.
To Next Page
