4 - 8 Operator’s Manual
4 Setup
Perform the following procedure:
1. Select [Import] or [Export] on the Fetal Gestational Age or Fetal Growth page.
2. Select the drive and file path where the data is located.
3. Select the data file to load or export, click [OK] to confirm.
The imported user-defined table for FG and GA must be a *.csv file. The format of the *.csv
file is described as follows:
–FG table
NOTE:
• Fill in the table according to the actual clinical values, except for those cells with bold
text.
• Value of standard deviation. Select from one of the following: None, ±1SD, ±2SD,
3%~97%, 5%~95%, 10%~90%.
• Unit of the measurement value: according to the table to import, select from mm, cm, g,
kg, cm² or mm².
• Row number (N) of the table: the maximum row number N in the column “No.”
• The third row is empty.
• GA value, Minimum value, Measurement value, Maximum value: enter the number of
days without the unit.
– GA table
Table Type Author Name SD Type Meas Value
Unit
SD Unit
FG The author name Value of standard
deviation
Unit of the
measurement
value
Unit of the
standard deviation
Row Num Row number (N)
of the table
No. GA Min Meas Value Max
1 GA value Minimum value Measurement
value
Maximum value
2 …………
……………
N …………
Table Type Author Name SD Type Meas Value
Unit
?
GA The author name Value of standard
deviation
Unit of the
standard deviation
Row Num Row number (N)
of the table
No. Meas Value SD(-) GA SD(+)
To Next Page
