BeneVision N22/BeneVision N19 Patient Monitor Service Manual 5-3
5.3 Optional Functional Assemblies
You can configure the following functional assemblies for this monitor:
Functional Assembly Part No. Description
Satellite module rack
115-033887-00
8-slot satellite module rack (SMR), with handle, hook, and 2
m cable
009-005122-00 Cable connecting the monitor and the SMR, 10 m
Secondary display
115-044994-00
22” secondary display (including the AC adapter and 2.3 m
cable)
115-044993-00
22” secondary display (including the AC adapter and 10 m
cable)
115-044997-00
19” secondary display (including the AC adapter and 2.3 m
cable)
115-044996-00
19” secondary display (including the AC adapter and 10 m
cable)
115-049288-00
22” secondary display (including the AC adapter and 5 m
cable)
115-049289-00
19” secondary display (including the AC adapter and 5 m
cable)
Split unit 115-051379-00 Split accessory material package (with the rotation function)
Wi-Fi 115-033755-00 Wi-Fi material package
Handle assembly
115-034030-00 Handle assembly (without encoder)
115-037270-00 Handle assembly (with an encoder)
Main unit battery 115-034132-00 Battery
iView module 115-055522-00 iView module package
Remote controller kit 115-045643-00 Remote controller kit
2D barcode scanner
115-039575-00 2D Barcode scanner (USB) kit
115-039635-00 2D Barcode scanner (support RFID) kit
This monitor is configured with wireless network functions and can be connected to network through wireless AP.
Contact Mindray Technical Support for assistance in connecting to a network.
5.3.1 Installing an SMR
The SMR can be connected to the patient monitor through the SMR connector via the SMR cable. For details, see
BeneVision N Series Patient Monitor Operator’s Manual (PN: 046-011259-00).
5.3.2 Installing an Secondary Display
To implement normal operation, use the video cable connection line to connect the secondary display to the
secondary display interface of monitor, connect the power supply, and turn on the secondary display. For details, see
