7-2 BeneVision N22/BeneVision N19 Patient Monitor Service Manual
ITEM NO. Description Qty FRU part number
9 Main control board PCBA Bay-Trail E3827 2GDDR 1 115-037490-00
10
Signal cable from the main control board to the main unit
interface and DC board
1 009-005098-00
11 Main unit interface and DC-DC board PCBA 1 115-037491-00
12 Main unit FPGA heat conducting pad 1 /
13 AC-DC heat conducting pad 3 1 /
14 AC-DC heat conducting pad 2 1 /
15 N22_N19 main unit label (Chinese) 1 /
16 Main unit housing waterproof foam 3
115-037486-00
18 CAPTIVE-SCREW 2
19 Main unit housing 1
17 USB port decoration cover 1 043-009126-00
20
Stainless steel cross recessed pan head screw GB9074.1-88
M4X55 with pad, passivated
4 /
21 AC-DC heat conducting pad 1 /
22 Upper cover of main unit 1 044-000660-00
23 Power supply 90-264VAC 16V/10A 1 022-000249-00
24
Power cord from the main control board to the main unit
interface and DCDC board
1 009-004996-00
25 Cable fixing. Viscose type fixing base GCF-063 2 /
26 ACDC insulating sheet 1 1 /
27
Small cross recessed pan head GB9074.5-88 M3X6 with pad
and plated with green color zinc
25 /
28 Battery cavity assembly 1 /
29 Main unit interface adapting assembly 1 /
30 Lithium battery 11.3V 5600mAh LI23I003A 1 115-034132-00
31 Main unit battery door (overmold) 1 043-006168-00
