7-4 BeneVision N22/BeneVision N19 Patient Monitor Service Manual
ITEM NO. Description Qty FRU part number
9 Display interface board PCBA (FRU) 1 115-044999-00
10 Alarm LED board interconnection line 1 009-005109-00
11
Speaker bracket 1
115-037489-00 Speaker 1
Speaker pad 1
12 D19 rear housing 1 043-005820-02
13
Display rear housing cover assembly 1 043-006465-01
Cable management cover (silkscreen) 1 043-008962-00
14 Encoder assmebly 1 115-050303-00
15 Handle assembly (without an encoder) 1 115-033716-00
16
Long side handle cover 1
115-035457-00
Display USB cover (overmold) 1
Short side handle cover (D19) 1
17 Key seat 1 043-006119-00
18 Switch keypad board PCBA 1 051-001920-00
19 Switch key assembly 1 049-001031-00
20 USB interface board interconnection line 1 009-005106-00
21
Display interface board and keypad board
interconnection line
1
009-005104-00
22
Display interface board and indicator & light sensor
board line
1
009-005124-00
23 USB interface board PCBA 2 051-001933-01
24 Indicator and light intensity sensor board PCBA 1 051-001918-00
25 Indicator light lamp shade 1 049-000872-00
26 D19 ornamental belt(FRU) 1 115-045003-00
To Next Page
