Installing Your System
3-2
3.2 Installation Requirements
3.2.1 Space Requirements
While installing the system, make sure there is enough space left for service and maintaining
operations, as well as for the system to dissipate heat and for the fluidic tubing to be properly
placed without extrusion. Specific requirements shown as follows:
 at least 500mm to the left/right of the system;
 at least 600mm above the system;
 at least 250mm behind the system;
 The ground where the system is placed shall be able to withstand at least 1880kg of
weight.
3.2.2 Power Requirements
WARNING
 Make sure the system is properly grounded.
 Before turning on the system, make sure the input voltage meets the
requirements.
CAUTION
 The connection of the system and the power shall only be completed by the
service engineer authorized by the manufacturer.
 All cables selected for use shall match the configuration of the system.
 The switch or circuit-breaker used for the system shall meet the following
requirements:
1. a switch or circuit-breaker shall be included in the building installation;
2. it shall be in close proximity to the equipment and within easy reach of
OPERATOR;
3. it shall be marked as the disconnecting device for the equipment.
Voltage
Frequency
Power
Loading Module
100V-240V~
50/60Hz
100VA
Unloading Module
100V-240V~
50/60Hz
100VA
Nonterminal
Analyzer Track
Module
100V-240V~
50/60Hz
100VA
