Understanding the CAL 8000 System
2-16
5 --- Exterior track waiting area
Figure 2-18 Tube Rack Moving Path of Nonterminal Track
Figure 2-19 Tube Rack Moving Path of Terminal Track
2.3.3 Unloading Module
The unloading module includes unloading assembly and unloading assembly cabinet. It
receives sample tube racks that have been processed from the unloading storage region of
the track module, so that users may collect them.
