13-20 Probes and Biopsy
Plastic/needle detachable needle-guided bracket:
No. Name Description
<1>
Support for needle-
guided bracket
Used for installing the needle-guided bracket on the probe.
<2> Angle block
Used for determining the angle of the biopsy. There are three
angle block specifications.
<3> Guiding block
Used for installing biopsy needles. There are five guiding block
specification for different biopsy needles.
<4>
Tab and groove for the
needle-guided bracket
Corresponding to the tab and groove of the probe.
<5>
Guiding block
specification (13G)
Matched with the corresponding biopsy needle (13G).
<6>
Biopsy needle
guiding hole
Used for installing the biopsy needle.
<7>
Angle block
specification (60°)
The corresponding biopsy angle is 60°.
