Barcode Reader B-7
B.2.1 Overview
1. LED Green: A barcode was successfully decoded.
Red: A data transmission error or reader malfunction occurred.
2. Scan window Scan the barcode.
3. Trigger Press to decode
B.2.2 Setting Up the Digital Imager Reader
B.2.2.1 Installing the Interface Cable
1. Plug the interface cable modular connector into the cable interface port on the bottom
of the reader handle and ensure the connector is properly secure.
2. Connect the other end of the interface cable to the host.
