2-14 System Overview
2.10 Control Panel
No. English Name Description
<1> /
Press the button to turn on the system, the system enters the
work status and the indicator becomes green.
<2> Volume Adjust the volume.
<3> /
Adjust the corresponding functions on the touch screen.
<4> /
<5> /
<7> /
<8> TGC Slide to adjust the depth gain.
<9> Patient Enter/exit Patient Info screen.
<10> Probe Switch probe and exam mode.
<11> Review Review the stored images.
<12> Report Open/close the exam report.
<13> End Exam End the current exam.
