System Overview 2-15
No. English Name Description
Enter/exit the textual comment status.
<15> Clear Clear the comments or measurement caliper.
<16> Cine
Press to enter the Cine Review status from non-cine status when
there is a multi-frame cine file playing.
<17> Body Mark Enter/exit Body Mark.
<18> M
Press to enter M mode, and rotate to adjust M mode gain. While
in 3D/4D mode, rotate the knob to make the 3D image to rotate
around X-axis.
<19> CW Enter CW mode.
<20> PW
Press to enter PW mode, and rotate to adjust PW or CW gain.
While in 3D/4D mode, rotate the knob to make the 3D image
rotate around Y-axis.
<21> Power Enter Power mode.
<22> Color
Press to enter Color mode, and rotate to adjust Color or Power
gain. While in 3D/4D mode, rotate the knob to make the 3D image
rotate around Z-axis.
<23> Dual
Enter Dual mode in Non-Dual mode.
Switch between the two display windows in the Dual mode.
<24> B Press to enter B mode, and rotate to adjust B mode gain.
<25> Single Enter single window in multiple window mode.
<26> 4D
Press to enter 4D function and rotate to make the 3D image
rotate.
<27> 3D Enter the 3D imaging function: Smart 3D or Static 3D.
<28> iTouch Optimize the image.
<29> Angle/Steer
Adjust the angle.
Adjust the steering of the probe.
Enter/exit the application measurement mode.
<31> Update
Switching key: Press to change the currently active window.
Start/stop image acquisition in iScape or 3D/4D mode.
Enter/exit the general measurement mode.
<33> Zoom
Rotate to enter the pan-zoom mode, and press to enter the spot-
zoom mode.
<34> Quad
Enter Quad mode in Non-Quad mode.
Switch between the four display windows in the Quad mode.
Adjust the depth in real-time imaging.
<36> Focus Change the focus position.
<37> Cursor Show/hide the cursor.
<38> Set
Confirm an operation. The function is same with the left-button of
the mouse.
<39> / Move the trackball to change the cursor position.
