Mindray DICOM - MPPS Preset

mindray DC7 Diagnostic Ultrasound System
13
1.4.4 MPPS Preset
Figure 7 DICOM MPPS Preset Screen
The main parameters of DICOM MPPS are described as below:
Name Description
Devices
After you set the server (s) in DICOM Server screen, the name (s) will
appear in the drop-down list, select the name of the MPPS server.
Service name Default is xxx-Worklist, user-changeable.
AE Title
Application Entity title, here, it should be consistent with that of the MPPS
server.
Port
DICOM communication port, 104 is default. Here, the port should be
consistent with that of the MPPS server port.
Maximum
Retries
0－9 times are optional, the default is 3. (Reserved)
Interval Time
（Sec）
5－1800 seconds, 15 seconds is default. (Reserved)
Timeout（Sec）
5-60s, in increments of 5s, and 15 is default. After user sending MPPS
for 15 seconds, the connection will be closed.
Add Add the DICOM service to the service list.
Cancel Click to cancel parameter preset.
Update
Select an item in the service list, change the parameters in the above
area, and click [Update] to update the item in the service list.
Delete Click to delete the selected service in the service list.
