2.6 Storage Commitment
Storage commitment is to ensure that the image data will be stored into the server
correctly.
Prerequisite: a default Storage Commitment server is needed, and a relative storage
server must be set.
Steps:
1. A default storage commitment server is preset.
2. Send image (and SR) to the storage server, the storage commitments are sent to the
commitment server automatically.
3. The state of the committed service will be returned with the column in iStation
screen marked with a tick if the commitment is succeeded. Otherwise the column will
not be marked.
2.7 Query/ Retrieve
The query/ retrieve function is to query and get the patient exam record from a specified
server.
Steps:
1. A query/ retrieve server is preset.
2. Path1: press <iStation> ->[Query/ Retrieve].
3. Path2: press <Patient> -> <iStation> -> [Query/ Retrieve].
4. Select the Source server, enter Search Key words and click [Query]. As shown in
figure below.
Figure 20 Query
