D Wireless LAN

Operator’s Manual D - 3

– If “DHCP” is selected, the IP address will be automatically obtained from the DNS server.

– If “Static” is selected (using a static IP address), enter the IP address.

IP address of the system should be in the same network segment with the server.

2. Click [OK] to save current setting. Click [Cancel] to exit.

D.3 EAP Network

For setting EAP network, contact Mindray Customer Service Department or the sales

representatives.
