Mindray ME8 Operator's Manual

4 - 6 Operator’s Manual
4 Setup
ICA/CCA && RAR
Set the measurement properties of ICA, CCA, Renal A and Aorta.
CARDIAC VALUE RANGE DISPLAY
Set whether to display the EMINCA study.
4.1.5 OB
Set the relevant information regarding the fetal gestational age, fetal growth formula and fetal
weight.
To set the default formula
Perform the following procedure:
1. On the [Fetal Gestational Age], [Fetal Growth] or [Fetal Weight] page, select an OB Item in
the left column.
2. Select a formula in the right column.
3. Click [Default].
The default formula is marked with a √.
To set the fetal weight display
Perform the following procedure:
1. Enter the [Fetal Calc] page.
2. Select the [Fetal Weight Unit].
Select Metric, English or English & Metric from the drop-down list.
3. Select the formula for calculating the weight percentile.
Select the formula from the drop-down list of [EFW-GP].
To import/export an OB Table or Formula
TIP:
Only imported user-defined tables can be exported.
Perform the following procedure:
1. Select [Import] or [Export] on the Fetal Gestational Age or Fetal Growth page.
2. Select the drive and file path where the data is located.
3. Select the data file to load or export, click [OK] to confirm.
The imported user-defined table for FG and GA must be a *.csv file. The format of the *.csv
file is described as follows:
–FG table
Table Type Author Name SD Type Meas Value
Unit
SD Unit
FG The author name Value of standard
deviation
Unit of the
measurement
value
Unit of the
standard deviation

Mindray ME8 Specifications

General

Brand	Mindray
Model	ME8
Category	Diagnostic Equipment
Language	English
