Patient Parameter Specifications Appendix
6 - 16 0070-10-0666-01 Trio™ Operating Instructions
6.2.10.3 Nellcor
®
SpO
2
Performance Requirements
Saturation Accuracy
Nellcor
®
SpO
2
Pulse Rate Performance Requirements
Pulse Rate Range and Accuracy
Update Rate
Update rate is 1 Hz.
NOTE: The sensor measurement wavelengths are nominally
660 nm for the red LED and 890 nm for the infrared LED.
Maximum optical power output for LED is 4 mW.
Sensor Compatibility: OxiMax series MAX-A, MAX-AL, MAX-N,
MAX-P, MAX-I, MAX-FAST, MAX-R, OxiCliq
A, OxiCliq N, OxiCliq P, OxiCliq I, D-YS, D-
YSE, D-YSPD, DS-100A, OXI-A/N and OXI-
P/I.
SpO
2
Display Range: 1 – 100%
SpO
2
Resolution: 1%
SENSOR ACCURACY
MAX-A, MAX-AL, MAX-N, MAX-P, MAX-I and
MAX-FAST
70% to 100% ± 2 digits
Below 70% unspecified
OxiCliq A, OxiCliq N, OxiCliq P and OxiCliq I 70% to 100% ± 2.5 digits
Below 70% unspecified
D-YS, DS-100A, OXI-A/N and OXI-P/I 70% to 100% ± 3 digits
Below 70% unspecified
MAX-R, D-YSE and D-YSPD 70% to 100% ± 3.5 digits
Below 70% unspecified
RANGE ACCURACY
20 to 250 bpm ±3 bpm
251 to 300 bpm Unspecified
