3-2
3.2.1 Plug-in Adapter/Plug-in Connector
The vaporizer is applicable to anesthetic delivery systems with plug-in connectors with an Ohmeda
Selectatec® compatible manifold system.
The holes in the plug-in adapter on the vaporizer fit onto the pins on the plug-in connector on the
anesthetic delivery system.
Interlock device
Plug-in adapter and pin
Plug-in connector
