Overview
Operator's Manual 7
2.4 Structure
TEEtransducerisaphasedarraytransducer,mountedinasealedtipattheendofa
gastroscope.Thetransducerisintendedforimagingoftheheartthroughtheesophagus
andthestomach.Amongthem,thetipofP7-3T/P7-3Ts/P7-3TE/P7-3TU/P8-2Ts/P8-2TU
rotatesusingthemotorcontrolpush-buttononthecontrolhandle,thetipofP8-3Tsrotates
usingthescanplanerotationwheelonthecontrolhandle,andthetipofXP8-2TUrotates
usingthecontrolpush-buttonsonthecontrolhandleelectronically.
Theprobetiprotatesusingthedeflectioncontrolwheelonthehandleforaccurate
positioningintheesophagus.
2.4.1 P7-3T/P7-3TE Transducer Functions by Part
12 3456 78
10
9
No. Name Function
1 Distaltipwith
transducer
Convertstheelectricalsignalintoanultrasonic
signal,focusingthesoundbeamsinagivendirection;
meanwhile,itreceivesthereectedultrasonicsignaland
convertsitintoanelectricalsignalfortransmissionover
thecable.Thelensonthesurfaceistheacousticlens.
Applyultrasoundgelontheacousticlensforcorrect
operation.
2 Deectionsection Deectstoobtainanoverallscanning.
3 Flexibleshaft Insertsintothemouthcavityoresophagus.Depthis
markedontheexibleshaft,unit:cm.
4 Controlhandle Operatesonthetransducerdeectionorrotation.
5 Left/RightDeection
controlwheel
Usedforcontrollingthetransducerleft/righttipdeection.
6 Up/DownDeection
controlwheel
Usedforcontrollingthetransducerup/downtipdeection.
7 Deectionlock Restrainthedeectionwheeladjustment.
8 Cable Transmitselectricalsignalsbetweenthetransducerbody
andconnector.
9 Motorcontrolpush-
buttons
Controlstoscanplanerotation.Range:0°–180°
