2.4.4 P8-3Ts Transducer Functions by Part
1 2 3 4 5 6 7 8
9
No. Name Function
1 Distaltipwith
transducer
Convertstheelectricalsignalintoanultrasonic
signal,focusingthesoundbeamsinagivendirection;
meanwhile,itreceivesthereectedultrasonicsignaland
convertsitintoanelectricalsignalfortransmissionover
thecable.Thelensonthesurfaceistheacousticlens.
Applyultrasoundgelontheacousticlensforcorrect
operation.
2 Deectionsection Deectstoobtainanoverallscanning.
3 Flexibleshaft Insertsintothemouthcavityoresophagus.Depthis
markedontheexibleshaft,unit:cm.
4 Controlhandle Operatesonthetransducerdeectionorrotation.
5 Deectioncontrol
wheel
Thelargerwheelonthehandleisforcontrollingtheprobe
tipdeection.
6 Scanplanerotation
wheel
Thewheelontopisthescanplanerotationcontrolwheel.
Controlstoscanplanerotation.Range:0°-180°.
7 Deectionlock Restrainthedeectionwheeladjustment.
8 Cable Transmitselectricalsignalsbetweenthetransducerbody
andconnector.
9 Connector Connectsthetransducertotheultrasonicdiagnostic
system.
2.4.5 XP8-2TU Transducer Functions by Part
1 2 3 4 5 6 7 8 9 10
11
