Mindray XP8-2TU - Brake Operation

TransducerControlsandInspection
16 Operator's Manual
P8-3Ts
1
2
2
3
3
1 Up/DownDeectioncontrolwheel
2 Turnlowerwheelcounterclockwisetomovethetipdown,90
°
minimum
3 Turnlowerwheelclockwisetomovethetipup,120
°
minimum
XP8-2TU
1
2
3
3
4
4
6
6
5
5
1 Left/RightDeectioncontrolwheel
2 Up/DownDeectioncontrolwheel
3 Turnupperwheelcounterclockwisetomovethetipleft,45
°
minimum
4 Turnupperwheelclockwisetomovethetipright,45
°
minimum
5 Turnlowerwheelcounterclockwisetomovethetipdown,90
°
minimum
6 Turnlowerwheelclockwisetomovethetipup,120
°
minimum
3.1.3 Brake Operation
Thetipdeectionbrakeinspectionshouldbeperformedonthetransduceraftertakingitout
oftheboxandpriortoeachexam.
1.
Conrmthebrakeisintheunlockedposition.
2.
Deectthetiptotheanteriordirection.
3.
Movethebraketothelockedposition.
4.
Conrmthatthetipislockedinthedeectedposition.
5.
Unlockthebrakeandconrmthetipstraightenseasily.
6.
Repeatsteps1-5fortheotherdirections.
