TransducerControlsandInspection
Operator's Manual 15
P7-3Ts/P7-3TU
1
2
3
3
4
4
6
6
5
5
1 Left/RightDeectioncontrolwheel
2 Up/DownDeectioncontrolwheel
3 Turnupperwheelcounterclockwisetomovethetipleft,45
°
minimum
4 Turnupperwheelclockwisetomovethetipright,45
°
minimum
5 Turnlowerwheelcounterclockwisetomovethetipdown,90
°
minimum
6 Turnlowerwheelclockwisetomovethetipup,120
°
minimum
P8-2Ts/P8-2TU
1
2
3
3
4
4
6
6
5
5
1 Left/RightDeectioncontrolwheel
2 Up/DownDeectioncontrolwheel
3 Turnupperwheelcounterclockwisetomovethetipleft,45
°
minimum
4 Turnupperwheelclockwisetomovethetipright,45
°
minimum
5 Turnlowerwheelcounterclockwisetomovethetipdown,45
°
minimum
6 Turnlowerwheelclockwisetomovethetipup,120
°
minimum
