TransducerControlsandInspection
18 Operator's Manual
1
Left/Right/Up/Downdeectionlock: -unlock
2
Left/Right/Up/Downdeectionlock: -lock
P8-3Ts
1
1 Up/Downdeectionlock:blue-lock
XP8-2TU
1 2
1 Left/Rightdeectionlock:blue-lock
2 Up/Downdeectionlock:blue-lock
3.1.4 Scanplane Rotation Operation
CAUTION
●
Do not use excessive force on the scanplane rotation control wheel at its outer
positions as this may damage the gastroscope mechanism.
●
The transducer scan plane can be rotated from 0° (transversal plane) via
90° (longitudinal plane) to 180° (transversal plane, left/right inverted). Or the
transducer scan plane can be rotated from 0° to 360° electrically. All planes in
between can also be chosen. This makes it possible to scan a conical imaging
volume.
