Mindray XP8-2TU - TEE Transducer Connector Without Lock Handle

TransducerControlsandInspection
22 Operator's Manual
Disconnecting the Transducer
Turnthelockhandle90°anticlockwisetoreleasethetransducer,andpullitoutstraight.
3.2.2 TEE Transducer Connector without Lock Handle
Connecting the Transducer
1.
InserttheTEEtransducerconnectorintothesystemport,thenpressinfully.
2.
Togglethelockinglevertothelockposition.
1
2
