TransducerControlsandInspection
Operator's Manual 21
Scanplane Rotation Inspection
Thescanplanerotationinspectiononthetransducershouldbeperformedaftertakingitout
oftheboxandpriortoeachexam.
1.
ConnectaTEtransducertotheultrasoundsystem.
2.
Priortoinsertingthetransducer,obtainanimage,e.g.,restthetransduceronasurface
andadjustthegaintovisualizetheimageontheultrasounddisplay.
3.
Pressthescanplanecontrolbuttonsonthehandletorotatethescanplane
counterclockwise(0°to180°)andclockwise(180°to0°).
4.
Conrmtheimageonthescreenchangesinrelationtothenumbersonthescanplane
indicator.
–
Whilepressingthemotorcontrolpush-buttons(notavailableforP8-3TsandXP8-
2TU),thetransducermotorshouldberunningastheimageischanging.
–
ForP8-3Ts:usethescanplanerotationwheeltocontroltherotation.
–
ForXP8-2TU:usethecontrolpush-buttonstocontroltherotation.
3.2 Connecting and Disconnecting the Transducer
TEEtransducershouldbeusedonlywithMindraycompatibleultrasonicdiagnosticsystems.
NOTE:
●
Beforeconnectingordisconnectingatransducer,freezeorturnofftheultrasonic
diagnosticsystem,otherwisetheultrasonicdiagnosticsystemorthetransducermay
malfunction.
●
Placethecableproperlytoavoidbeingtreadedorwrappingwithotherdevices.DO
NOTallowthetransducerheadtohangfree.
3.2.1 TEE Transducer connector with Lock Handle
Connecting the Transducer
1.
Turnthelockhandlehorizontally,andinserttheconnectorfullyintotheconnector.
2.
Turnthelockhandle90°clockwisetolockitsecurely.
