TransducerControlsandInspection
20 Operator's Manual
1 90°rotationsagittaltomirrorimageoftransverseplane
2 90°rotationtransversetolongitudinalplane
3 Conicimagingvolume
4 Quadrantslledbyrst90°rotation
5 Quadrantslledbysecond90°rotation
Rotation Control of P8-3Ts
1
2
3
1 ShortAxis
Angle=0°
2 LongAxis
Angle=90°
3 ShortAxis
Angle=180°
Scanplane Indicator
Fororientationpurposes,ascanplaneindicatorhasbeenincorporatedonthesystem
display.Theactualscanplaneangleisindicatedbyamarker,andthevalueisalso
displayedasshowningurebelow.Thescanplaneanglerangesfrom0°to180°.
