TransducerControlsandInspection
Operator's Manual 19
Rotation Control
Figure 3-1 P7-3T/P7-3TE
Figure 3-2 P8-2Ts/P8-2TU
Figure 3-3 XP8-2TU
Fororientationpurposes,theusermaychoosetostartscanninginoneofthetransverse
planes,forinstancethestandardmonoplaneindicatedas0°onthesystemmonitor.After
rotatingthescanplane90°,scanningoccursinthelongitudinalplane,sweepingthrough
twooppositequadrantsofthecone.Whenthescanplanerotates90°furtherinthesame
direction,scanningoccursinthemirrorimageofthersttransverseplane.Theonlytwo
planesthatareequivalentarethetwotransverseplanes;onebeingthemirrorimageofthe
other.Asshowningurebelow,a180°rotationofthescanplanellsallfourquadrantsof
theconicimagingvolume.
Thedirectionofthetipoftheendoscopeiseasilysteeredusingthedeflectioncontrol
wheelsonthehandleoftheinstrumenttoallowexactpositioningofthetransducerinthe
esophagus.
