Mindray XP8-2TU - P8-2 Ts;P8-2 TU Transducer Functions by Part

Overview
Operator's Manual 9
2.4.3 P8-2Ts/P8-2TU Transducer Functions by Part
12 39
11
45678
10
No. Name Function
1 Distaltipwith
transducer
Convertstheelectricalsignalintoanultrasonic
signal,focusingthesoundbeamsinagivendirection;
meanwhile,itreceivesthereectedultrasonicsignaland
convertsitintoanelectricalsignalfortransmissionover
thecable.Thelensonthesurfaceistheacousticlens.
Applyultrasoundgelontheacousticlensforcorrect
operation.
2 Deectionsection Deectstoobtainanoverallscanning.
3 Flexibleshaft Insertsintothemouthcavityoresophagus.Depthis
markedontheexibleshaft,unit:cm.
4 Controlhandle Operatesonthetransducerdeectionorrotation.
5 Deectionlocklever Restrainthedeectionwheeladjustment.
6 Left/RightDeection
controlwheel
Usedforcontrollingthetransducerleft/righttipdeection.
7 Up/DownDeection
controlwheel
Usedforcontrollingthetransducerup/downtipdeection.
8 User-denedkey SetbytheuserintheUltrasoundsystempreset
9 Cable Transmitselectricalsignalsbetweenthetransducerbody
andconnector.
10 Motorcontrolpush-
buttons
Controlstoscanplanerotation.Range:0°–180°
11 Connector Connectsthetransducertotheultrasonicdiagnostic
system.
