Examination
Operator's Manual 29
4
Examination
TheactualexaminationwiththemultiplaneTEETransducerisbeyondthescopeofthis
manual.Therearemanymedicalarticlesandbooks,whichverythoroughlyaddressthis
topic.Therearehoweverspeciccautionsthatshouldbeconsidered.
Theoperatorshouldhaveadequateclinicalexperienceandreceivedrelatedtraining.
WARNING
The physician must take into account all possible factors before starting the
examination.
4.1 Pre-Exam Inspection
Thefollowinginspectionsshouldbeperformedpriortoeachexam.
•
Performvisualtactileinspection,see"3.1.1 VisualandTactileInspection".
•
Performtipdeectioninspection,see"3.1.2 TipDeectionControl".
•
Performbrakeinspection,see"3.1.3 BrakeOperation".
•
Performscanplanerotationinspection,see"3.1.4 ScanplaneRotationOperation".
•
Performleakagetestorbite-guardinspectiontest,see"3.3 ElectricalSafety".
•
Cleananddisinfecttransducer,see"5 CleaningandDisinfection".
WARNING
●
To avoid injury to the patient, Mindray recommends performing the above
procedures prior to each exam.
●
To avoid injury to the patient, do not use the transducer if any metallic
protrusions, holes, rough spots, cracks, or dents are found.
●
To avoid injury to the patient, if during the deflection test, a sharp “U-turn” of
the transducer tip is observed (the transducer tip angle exceeds the maximum
deflection angles), do not use the transducer. Call Mindray or your local
representative.
●
Some gels and disinfectants can cause an allergic reaction in some individuals.
4.2 Couple Gel, Sheath, and Bite-guard
4.2.1 Couple Gel
Applyasu󰀩cientamountofwater-solubleacousticcouplinggelonthetransduceracoustic
window.
