TransducerControlsandInspection
Operator's Manual 17
P7-3T/P7-3TE
1
2
3
4
1 Left/Rightdeectionlock:white-unlock
2 Left/Rightdeectionlock:red-lock
3 Up/Downdeectionlock:white-unlock
4 Up/Downdeectionlock:red-lock
P7-3Ts/P7-3TU
1 2
1 Left/Rightdeectionlock:blue-lock
2 Up/Downdeectionlock:blue-lock
P8-2Ts/P8-2TU
1
2
