Assembly Part # Description Notes Quantity
B 2777034 MTR/TUBE ASM 80# 54" TRV BT *MOTOR & TUBE* *54* *4* *COPILOT* 1
F 2777035 MTR/TUBE ASM 80# 54" TRV-M BT *MOTOR & TUBE* *54* *4* *EUROPE ONLY* 1
D 2777036 MTR/TUBE ASM 80# 60" RT TRV BT *MOTOR & TUBE* *60* *4* 1
G 2777037 MTR/TUBE 80# 60" RT TRV-M BT *MOTOR & TUBE* *60* *4* *EUROPE ONLY* 1
P 2777042 MTR/TUBE ASM 80# 72" *MOTOR & TUBE* *72* *4* *EUROPE ONLY* 1
J 2777398 CTR HSG,CB,80#,SW, UP TO 60" *TUBE* *4* 1
DD 1378132 PROP IND 233160 WDLS WDG II *4* *80LB THRUST* 1
T 2889460 SEAL & O-RING KIT *80LB THRUST* *4* 1
Item Part # Description Notes Quantity
120
✖
TUBE-COMP,WHT,54",1/4", "M",T2 *54”* 1
✖
TUBE-COMP,WHT,60",1/4", "M",T2 *60”* 1
✖
TUBE-COMP,WHT,60”,1/4”, WALL,T2 *60”* 1
✖
TUBE-COMP,WHT,72",1/4", "M",T2 *72”* 1
✖
TUBE-COMP,WHT,72",1/4" WALL,T2 *72”* 1
122 2307312 BEAD-FERRITE *M SKU* *EUROPE ONLY* 1
124 2262658 PIN-DRIVE 1" X 3/16" S/S *80LB THRUST* *4* 1
126 2091701 WASHER-PROP (LARGE) *80LB THRUST* *4* 1
128 2093101 NUT-PROP,NYLOC,LG,MX101 3/8 SS *80LB THRUST* *4* 1
130 2331161 PROP-WW2 4" WELDED *4* *80LB THRUST* 1
132 188-094 BRUSH W/TERMINAL *4* *80LB THRUST* 2
134 975-041 SPRING - TORSION *4* *80LB THRUST* 2
p
✖
RIVET - .25" *4* *80LB THRUST* 6
136
640-133 LEADWIRE RED 10AWG 66-1/4 XLP *COPILOT* *54”* 1
640-126 LEADWIRE RED 10AWG 71" XLP *60”* 1
640-155 LEADWIRE RED 10AWG 83.625 XLP *72”* 1
138
640-025 LEADWIRE BLK 10 AWG 66 3/4 XLP *COPILOT* *54”* 1
640-022 LEADWIRE BLK 10 AWG 72.5 XLP *60”* 1
640-053 LEADWIRE BLK 10 AWG 82.375 XLP *72”* 1
p
✖
BRUSH HOLDER *4* *80LB THRUST* 2
p
✖
CONNECTOR 1/4 MALE TAB QD *4* *80LB THRUST* 2
140 2-100-214 ARM ASSY 24V 4" 80# (WW2) *80LB THRUST* *4.0* 1
142 140-010 BEARING - BALL *80LB THRUST* *4.0* 1
144
✖
CTR HSG ASM 4.0" SW CB MGNTZD *80LB THRUST* *4.0* 1
146 2-300-370 BRUSH END HSG ASY SW/W 4.0 *80LB THRUST* *4.0* 1
148 421-376 HSG PLN END 4" SW WHT BS *80LB THRUST* *4.0* 1
24 Volt 4” Motor Parts List
l Only available with models factory installed with CoPilot.
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
t Only available with models factory installed with i-Pilot.
 Only available with models factory installed with i-Pilot Link.
