MINN KOTA RIPTIDE TERROVA - Page 46

Item Part # Description Notes Quantity
150 701-009 O-RING *80LB THRUST* *4.0* 2
152 701-043 O-RING *80LB THRUST* *4.0* 2
154 830-027 SCREW - SELF-THREAD 10-32X2.25 *80LB THRUST* *4.0* 2
156 830-094 THRU BOLT 12-24 x 10.31 *80LB THRUST* *4.0* 2
158 990-051 WASHER - STEEL THRUST *80LB THRUST* *4.0* 1
160 990-052 WASHER - NYLATRON *80LB THRUST* *4.0* 1
162 582-013 CLIP, RETAINING SHORT *80LB THRUST* *4.0* 1
164 973-025 SPACER - BRUSHPLATE *80LB THRUST* *4.0* 2
166 992-010 WASHER - BELLEVILLE *80LB THRUST* *4.0* 2
168 990-045 SPACER - THRUST *80LB THRUST* *4.0* 1
170 788-040 RETAINING RING 1
172 880-025 SEAL 2
174 725-095 PAPER TUBE, SEAL 1
176 144-017 BEARING, FLANGE 1
178 9-738-015 BRUSH PLATE ASM 4" CTR BUNG *4”* *80LBS THRUST* 1
l Only available with models factory installed with CoPilot.
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
t Only available with models factory installed with i-Pilot.
 Only available with models factory installed with i-Pilot Link.
