36 Volt 4.5” Motor Parts List
Assembly Part # Description Notes Quantity
C 2777083 MTR/TUBE 112# 60" RT TRV BT *MOTOR & TUBE* *60* *4.5* 1
E 2777084 MTR/TUBE 112# 72" RT TRV BT *MOTOR & TUBE* *72* *4.5* 1
L 2777198 MTR/TUBE 112# 87" RT TRV BT *MOTOR & TUBE* *87* *4.5* 1
H 2777343 CTR HSG,CB,112#,SW, UP TO 60" *TUBE* *4.5* 1
K 2777344 CTR HSG,CB,112#,SW, 72" *TUBE* *4.5* 1
R 2777356 CTR HSG,CB, 112#, SW, 87" *TUBE* *4.5* 1
CC 1378160 PROP KIT 2341160 112# WW2 *4.5* *112LB THRUST* 1
U 2881450 SEAL & O-RING KIT *112LB THRUST* *4.5* 1
Item
Part # Description Notes Quantity
190
✖
TUBE-COMP,WHT,72",1/4" WALL,T2 *72”* 1
✖
TUBE-COMP,WHT,60",1/4" WALL,T2 *60”* 1
✖
TUBE-COMP, WHT, 87",, 1/4" WALL *87"* 1
192 2262658 PIN-DRIVE 3/16" DIAMETER LG (SS) *112LB THRUST* *4.5* 1
194 2091701 WASHER-PROP (LARGE) *112LB THRUST* *4.5* 1
196 2093101 NUT-PROP,NYLOC,LG,MX101 3/8 SS *112LB THRUST* *4.5* 1
198 2341161 PROP-WW2 4.5" WELDED *112LB THRUST* *4.5* 1
200 188-095 BRUSH *4.5* *112LB THRUST* 2
202 975-045 SPRING - TORSION *4.5* *112 LB THRUST* 2
p
✖
RIVET - .25" *4.5* *112LB THRUST* 6
204
640-145 LEADWIRE RED 10AWG 75 7/8" GPT 1
640-149 LEADWIRE RED 10AWG 88" GPT *72”* 1
640-157 LEADWIRE RED 10 AWG 100" GPT *87"* 1
206
640-049 LEADWIRE BLK 10AWG 88.50" GPT *72”* 1
640-045 LEADWIRE BLK 10 AWG 76.5 GPT *60”* 1
640-057 LEADWIRE BLK 10A 100.5" GPT *87"* 1
p
✖
BRUSH HOLDER *4.5* *112LB THRUST* 2
208 9-738-011 BRUSH PLATE *4.5* *112LB THRUST* 1
210 2260731 TERMINAL 1/4" MALE TAB-THREE *4.5* *112LB THRUST* 2
212 2307312 BEAD-FERRITE *4.5* *112LB THRUST* 1
214 2-100-245 ARMATURE ASY 4.5"LWR UNIT *112LB THRUST* *4.5* 1
216 140-014 BEARING-BALL 6000 *112LB THRUST* *4.5* 1
218
✖
CTR HSG ASY 4.5" MAG FW CB *112LB THRUST* *4.5* 1
220 2-300-176 BRUSH END HSG ASY 4.5" SW *112LB THRUST* *4.5* 1
222 421-241 PLAIN END HSG 4.5" PNTD SW *112LB THRUST* *4.5* 1
224 701-009 O-RING *112LB THRUST* *4.5* 2
226 701-098 O-RING, 98MM X 2MM *112LB THRUST* *4.5* 2
l Only available with models factory installed with CoPilot.
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
t Only available with models factory installed with i-Pilot.
 Only available with models factory installed with i-Pilot Link.
48 | minnkotamotors.com
©2022 Johnson Outdoors Marine Electronics, Inc.
