Item Part # Description Notes Quantity
228 144-017 BEARING, FLANGE 1
230 2053410 SCREW-#8-32 X 1/2 TRI-LOBE HEX *112LB THRUST* *4.5* 2
232 830-194 THRU BOLT 12-24 X 10.31 COATED *112LB THRUST* *4.5* 2
234 990-051 WASHER - STEEL THRUST *4.0* *112LB THRUST* *4.5* 1
236 990-052 WASHER - NYLATRON *112LB THRUST* *4.5* 1
238 582-016 CLIP-RETAINING, SONAR *112LB THRUST* *4.5* 1
240 992-011 WASHER - BELLEVILLE *112LB THRUST* *4.5* 2
242 990-011 WASHER-SHIM OD 1",ID.630"SS *112LB THRUST* *4.5* 1
244 788-040 RETAINING RING 1
246 880-025 SEAL 2
248 725-095 PAPER TUBE, SEAL 1
250
✖
O-RING, 107 MM X 1.78MM, 70 BUNA 1
l Only available with models factory installed with CoPilot.
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
t Only available with models factory installed with i-Pilot.
 Only available with models factory installed with i-Pilot Link.
minnkotamotors.com | 49
©2022 Johnson Outdoors Marine Electronics, Inc.
PARTS DIAGRAM & PARTS LIST
