Assembly Part # Description Notes Quantity
SS 2997064 STEERING HSG ASM 12V SW 1
TT 2997065 STEERING HSG ASM 24V SW 1
UU 2997063 STEERING HSG ASM 36V SW 1
VV 2992737 LIFT ASSIST ASM 55# SW PA6 1
WW
2992738 LIFT ASSIST ASM 80# SW PA6 1
XX 2992739 LIFT ASSIST ASM 112# SW PA6 1
CCC 2776562 STEERING HSG TOP SW / GEAR KIT 1
DDD 2777060 STEERING MOTOR KIT, 12V T2 1
EEE 2777061 STEERING MOTOR KIT, 24V T2 1
GGG 2777063 STEERING MOTOR KIT, 36V SW T2 *DUAL MOTOR* 1
GG 2771523 COLLAR-FRONT/BACk, LFT ASST KIT 1
HH 2771505 DEPTH COLLAR KIT, TERROVA BT 1
Item Part # Description Notes Quantity
360 2326567 STEERING HSG,BTTM,SW,WHT 1
362
✖
PIN-ROLL 5/16" X 1/2" 4
364
✖
SHAFT-GEAR, FIRST CLUSTER 1
366
✖
SHAFT-GEAR,INTERMED.CLUSTER 1
368
✖
SHAFT-GEAR, THIRD CLUSTER 1
370 2322210 GEAR & PINION,DR. HSG, STAGE 2 1
372 2302250 GEAR & PINION,DR. HSG, STAGE 3 1
374 2302255 GEAR & PINION,DR. HSG, STAGE 4 1
376 2321730 SPACER,GEAR CLUSTER 1
378
✖
MOTOR, STEERING 12V FW T2 *SEE DDD* 1
✖
MOTOR, STEERING 24V FW T2 *SEE EEE* 1
✖
MOTOR, STEERING 36V FW T2 *SEE GGG* 2
380 2322215 PINION GEAR, DR.HSG, STAGE 1 1
382
2322520 CASE-MOTOR,STRG HSG,TOP *12 VOLT* *24 VOLT* 1
2322521 CASE-MTR, STEER HSG, TOP w/HOLES *36 VOLT* 1
384 2322525 CASE-MOTOR,STRG HSG,BTM 1
386 2051710 SPLIT LOCK WASHER 3MM 4
388 2043412 SCREW-#8-18 X 3/4 TY AB SS PPH 1
390
✖
LEADWIRE,STEERING MOTOR *SEE DDD, EEE OR GGG* 1
392 2308601 BREATHER FILTER, DR.HOUSING 1
394 2322031 TUBE-OUTPUT, SALTWATER 1
396 2322200 GEAR-OUTPUT 1
398 2327315 BUSHING,ALUMIN. SPACER ST 2
l Only available with models factory installed with CoPilot.
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
t Only available with models factory installed with i-Pilot.
 Only available with models factory installed with i-Pilot Link.
54", 60" & 72" Motor Steering Housing & Lift Assist Parts List
