Item Part # Description Notes Quantity
400 2321704 WASHER-THRUST, STEERING 2
402 2321720 SHIM,O-RING 2
404 2321510 COLLAR-DRIVE,BOTTOM 1
406 2324608 O-RING,224, STR HSG 2
408 2321530 LINER OUTPUT TUBE, LIFT ASSIST 1
410 2324604 O-RING, CASE SEAL 1
412
✖
HOUSING-STEERING, TOP, SW 1
414 2323408 SCREW-#8-32 X 2.0 SHCS SS 7
416 2322601 PIN-LATCH, SS 1
418 2321702 WASHER-FLAT .375 NYLON 2
420 2263011 E-RING 3/8 DIA. SHAFT 2
422 2322702 SPRING, LATCH PIN SS 2
424 2323410 SCREW-#8-32 X .75 SHCS SS 1
426 2326547 HOUSING-RIGHT, LIFT ASSIST PA6 1
428 2326542 HOUSING-LEFT, LIFT ASSIST PA6 1
430
2997903 ASSEMBLY-HUB/SPRING, 55# INCNL 1
2997904 ASSEMBLY-HUB/SPRING, 80# INCNL 1
2997905 ASM-HUB/SPRING,112# INCN 1
432 2322300 GUIDE,DR.DOG, LIFT ASSIST 1
434 2328605 ENGAGEMENT DOG, LIFT ASST 1
436 2322726 SPRING,COMPRESSION,.360" OD SS 1
438 2322610 PIN-AXLE, LIFT ASSIST 1
440 2323430 SCREW-#10-24 X 1-3/8, PPH 5
442 2333101 NUT-HEX #10-24 UNC-2B NYL SS 5
444 2372103 SCREW-#6 X .375 PLASTITE SS 4
446 2321955 BRACKET, LIFT ASSIST 2
448 3393450 SCREW-#6-19 X .75 PPH HI-LO 2
450 2327310 BUSHING, PIVOT PIN 2
452 2321505 DEPTH COLLAR, LIFT ASSIST 1
454 2321702 WASHER-FLAT .375 NYLON 1
456 2260906 KNOB-SOFT GRIP,HG/DR,SS 1
458 3393450 SCREW-#6-19 X.75 PPH HI-LOW SS 4
460 2321523 COLLAR-FRONT, LIFT ASSIST, SW 1
462 2321527 COLLAR-BACK, LIFT ASSIST, SW 1
464 2323429 SCREW, #6-32 x .50” SS BHCS 1
466 2323110 NUT-HEX, 6-32 NYLOK SS 1
468 2053422 SCREW-M3-.5 X 10 PPH, ZPS 4
