Assembly Part # Description Notes Quantity
ZZ 2774066 CTRL BRD, 24/36V TRV BT w/SHRNK 1
AAA 2774067 CTRL BRD, 12V TRV BT w/SHRNK *i-PILOT/i-PILOT LINK* 1
BBB 2774069 CTRL, BRD, 24/36V IP TRV BT, SHRNK *i-PILOT/i-PILOT LINK* 1
AA 2994864 BAG ASSY-TERROVA/V2,MNTG HDW 1
Item Part # Description Notes Quantity
490
2321908 BASE-EXTRUSION, MACH, SW 1
2998622 BASE, EXTRUSION ASM HT SW *i-PILOT LINK* *87"* *112LB THRUST* 1
492 2322912 PIN-ROLL .1875 X 1.000 SS 2
494 2332103 l SCREW-#8-18 X 1/2 (SS) *COPILOT* 1
496 2994097 l TRANSMITTER ASY, TRRV CPLT *COPILOT* 1
498 2322603 PIN-PIVOT, SS 1
500 2333100 NUT-SPEED (SS) 3HP-SS 2
502 2320406 HANDLE, RELEASE, SW 1
504 2322604 BUSHING,HANDLE,GOBEIL 2
506 2071716 WASHER-FLAT SS .253 x .470 1
508 2322701 SPRING, TORSION 1
510 2301700 SPACER-RELEASE LEVER-BRASS 1
512 2073408 SCREW-1/4-20 X 7/8 PPH S/S 1
514 2321941 BRACKET, STRAIN RELIEF SW 1
516 2321951 BRACKET, SIDEPLATE SW 1
518 2323412 SCREW-#8-18 X .25 PPH SS TY B 4
520 2321706 WASHER-FLAT #8 .50 OD/.188 SS 4
522 2325115 PAD, RUBBER REST, BLACK 4
524
2323910 RAMP-MOTOR, RIGHT 3-5/8" 1
2323930 RAMP-MOTOR, RIGHT 4" 1
2323931 RAMP-MOTOR, RIGHT 4.5" 1
526 2374197 l PCB ASY COPLT REC. TERROVA *COPILOT* 1
528 2994201 ARM/SUPPORT BLOCK ASSY,R,SW 1
530
2321920 PLATE-SKID, RIGHT FW *80 LBS* *55 LBS* 1
2321922 PLATE-SKID, RIGHT *112 LBS* 1
532
2323915 RAMP-MOTOR, LEFT 3 5/8" 1
2323935 RAMP-MOTOR, LEFT 4" 1
2323936 RAMP-MOTOR, LEFT 4.5" 1
534 2324706 INSERT-MOTOR RAMP,METAL,SS 2
536 2994203 ARM/SUPPORT BLOCK ASSY,L,SW 1
Mount Parts List
l Only available with models factory installed with CoPilot.
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
t Only available with models factory installed with i-Pilot.
 Only available with models factory installed with i-Pilot Link.
58 | minnkotamotors.com
©2022 Johnson Outdoors Marine Electronics, Inc.
PARTS DIAGRAM & PARTS LIST
