Item Part # Description Notes Quantity
538 2332104 SCREW-1/4-20 X 5/8 S/S 1
540 2322716 SPRING, EXTENSION, T2 2
542 2321700 WASHER #10 SS 2
544 2323422 SCREW-#10-24 X .25" PPH SS MCH 2
546 2322921 STAND-OFF, ALUM. ANODIZED 2
548
2321925 PLATE-SKID, LEFT *80 LBS* *55 LBS* 1
2321927 PLATE-SKID, LEFT *112 LBS* 1
550 2323403 SCREW-1/4-20 X.375 MCH SS CRPH 3
552 2320218 COVER, HANDLE COSMETIC SW 1
554 2383446 SCREW-#8-16 X .50" PLASTITE SS 2
556 2320830 LOCKING TAB,PWR/BAT.METER 1
558 2383428 SCREW-#4-24 X 3/8 HI-LO SS 2
560 2320202 CAP-DUST,CONNECTOR, MALE 1
p
2323406 SCREW-#10-24 X .50 CRPH SS 2
562 2090651 LEADWIRE,10 GA 1
564 2321310 STRAIN RELIEF 1
566 2323405 SCREW-1/4-20 X 1/2" MCH SS 5
568 2307312 BEAD-FERRITE 1
570
2991271 COIL CORD ASY 54"/60" NON-US2 *54"* *60"* 1
2991275 COIL CORD ASY 72" NON-US *72"* *112 LBS* 1
2991277 COIL CORD ASM 84" NON-US *87"* *112 LBS* 1
572 2323928 SIDEPLATE-LEFT, RT TERROVA 1
574 2323402 SCREW-1/4-20 X .375 T-L, ZP 2
576 2326531 HOUSING-CENTER, RT/ST 1
578 2325658 DECAL,BM/CN/PWR STATUS SW 1
580
2074080 BATTERY METER, 12V, SW 1
2074081 BATTERY METER, 24V, SW 1
2074082 BATTERY METER, 36V, SW 1
p
2321721 SHIM, 2 X 4 X .025" 1
582 2320710 TERMINAL-AMP (T-TAB) 1
584 2325401 SHRINK TUBE-.375 OD X 2.25" 1
p
2321315 HOLDER-CONNECTOR,NYLON,BLACK 1
586 2305403 SHRINK TUBE-.500 IDX1.0" ADHSV *SALTWATER* 4
588 2322901 STRAIN RELIEF, HEYCO P/N 1852 1
590 2323923 SIDEPLATE-RIGHT, RT/ TERROVA 1
592 2323405 SCREW-1/4-20 X 1/2" T-L SS 4
594 2263462 SCREW-1/4-20 X 2" S/S PPH ADJT 6
l Only available with models factory installed with CoPilot.
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
t Only available with models factory installed with i-Pilot.
 Only available with models factory installed with i-Pilot Link.
