Mira Advance Installation Guide

14
1306246-W2-A
1 2
Remove the cover screw. Remove the cover, the service tunnel and the bungs.
Determine the cable and pipe supply either top or
bottom or rear connection.
Turn the inlet connector to suit supply
pipe. Do not trap the green wire.
Complete any soldering required away
from the appliance.
3 4

Mira Advance Specifications

General

Temperature Control	Thermostatic
Warranty	2 Years
Power Ratings	9.8 kW
Water Connection	15 mm
Outlet Connection	1/2"
Water Pressure	0.7 - 10 bar
Cable Entry Points	Bottom entry
Safety Features	Overheat protection
Approvals	WRAS
