Installation and Programming Manual
Mircom Technologies Inc All Rights Reserved LT-1034 Rev.1
Page 20 of 54
Once all the ISDs are enrolled, the NMC LCD should display “SYSTEM NORMAL” with only the GREEN AC
power LED on (after Date and Time have been entered).
Note: Each ISD can be moved to another outlet location at anytime. A programmable delay feature (global) is
available via the NMC keypad.
Default is 90 seconds in Canada, 200 seconds in the US.
The Verification process should now commence on the installed FIRE-LINK system.
Please refer to Section 7.0 for testing and maintenance of all ISDs on the network.
For installing large numbers of ISD units in typical installations: Use the Dealer ‘FIRE-LINKLOAD’ database
and barcode scanner (Dealer provided).
4.2 Installation Checklist (Quick-Start):
o In FIRE-LINKLOAD program, create and Input the ‘Job File’ database information.
o Go to ‘ISD’ input screen.
o Input Address (suite number) and check box if a message unit.
o Scan barcode (VID#) provided on back of ISD unit.
o Write this suite number in space provided on back housing of ISD unit. Use non-smearing ink/felt pen.
o Repeat for all ISD units for this network install.
o Connect serial cable to powered NMC (either now or preferably later on site).
o Go to ‘CONNECT’ in FIRE-LINKLOAD program.
o Download (Send Job) Job File database info to NMC.
o Go to site with all ISD devices.
o Install all ISD units into suites based on suite numbers written on back of ISD housing and check for 12V
halogens in the suites. If any found, turn them ON until after
enrolment is completed. See Section 8.0 for
missing ISD devices.
o An Electrician should have installed the PPC and NMC unit prior, as per installation instructions.
o Power up NMC, install battery and input Date and Time via keypad menu.
o In NMC menu go to ‘Auto-Prgm’ and enroll ISD units.
Enrolment time can take up to 2 min. for 40 ISDs, 10 min. for 120 ISD units.
o Any missing units should be rectified immediately. See Section 8.0, Trouble-shooting guide for Missing and
Unknown devices.
