Installation and Programming Manual
Mircom Technologies Inc All Rights Reserved LT-1034 Rev.1
Page 34 of 54
Enter the 8 character VID number found on the back of the ISD unit, on the Barcode Label, followed by ENT.
Follow the procedure outlined in Section 5.13 for Enrolling an ISD or see procedure below.
NOTICE: FOR ENROLLING SINGLE ISDs, FOLLOW THESE STEPS:
1. Go to ‘EDIT ADDR’ menu (see Section 5.12)
2. Press ‘8’ and ‘9’ simultaneously
3. Go to the ‘VIEW MISSING’ menu and press ENT
4. Choose the unenrolled ISD you want to enroll onto the network and press ‘3’ (‘3’ = E for ENROLL)
5. The NMC will attempt to enroll this device.
If it is successful, a message will appear ‘ENROLL SUCCESSFUL!!’ and the ISD will be moved to
the enrolled ISDs category. If the enrollment is not successful ‘ENROLL FAILED!’ will appear on
the display. You should then verify this units VID number. If it is correct, then verify why the NMC
cannot see it on the network. (Location-unplugged? 12V Halogen present? faulty ISD? etc.).
5.16 Setting the System Parameters
The NMC has several system parameters that may be adjusted globally to suit specific needs or applications.
Please note however that adjusting these parameters may violate ULC, UL, NFPA and/or local
jurisdictional (AHJ) fire alarm codes and standards. The global programmable parameters are:
ISD Signal Rate
Signal Silence Inhibit
Trouble Notification
Auto Alarm Silence
Clear Trouble and Alarm Logs
ISD Signal Rate
Changes the ISD audible alarm rate from Temporal [default] to March Time or to Continuous. All ISDs will
alarm at the same chosen signal rate.
Signal Silence Inhibit
Changes the Silence Inhibit feature on the NMC from disabled [default] to enable. If left disabled, the ISDs can be
silenced from the NMC keypad at any time during the alarm condition. If enabled, the ISDs may be silenced by
pressing the Alarm Silence button on the NMC keypad after
the selected time has elapsed. The selectable times
are: 1 min. [default], 5, 10 and 20 minutes.
(In Canada, this will NOT effect the operation of the 10 minute silencing feature on the ISDs).
Trouble Notification
Allows for trouble conditions to be reported by the NMC on the following conditions:
ISD Missing
ISD Battery Trouble (Low or Missing)
NMC Date/Time Loss
The above conditions are factory default
to put the NMC into trouble mode if any of these conditions are
present.
