QX-5000 Windows Configuration Utility User Guide
19
Configuring the System
Through the System Configuration Window you can
• Set alert and evacuation tones
• Select the manual evacuation mode
• Set the panel options
• Add QMPs and QDVs and set them up
Accessing the System Configuration Window
1. Select “System” from the left pane. The right pane displays the system configuration.
•Select Edit-->Properties from the main menu or double-click in the right pane. The System Configuration
Window displays.
Advanced Options
You will rarely need to change the Advanced Options. To open the Advanced Options Window, click the Advanced
button in the System Configuration window.
Note: If the QDV Installed checkbox is not checked, the QDV-1000 configuration will not be transmitted to
the panel; however, you can still build the QDV configuration.
• If the All Evacuation checkbox is checked, the panel will
ignore all General Alarm inputs in the Input
Configuration section.
• If the Disable alarm pre-tone checkbox is not selected
(which means that the pre-tone is enabled), and a QDV
is installed, then QDV Channel-1, Part-1, must have a
message and its repeat must be set to its maximum
value (255).
