3. Installation, Connection and Start-up
Keep the reader away from sources of electromagnetic fields
(f = 125 kHz: video terminals, power supplies, rotary machines, etc.).
Install readers in accordance with §4 recommendations.
To install and start up the LDM 320, take the following steps:
Install the software on the PC.
Connect the reader to the PC.
3.1. Hardware Installation
The LDM 320D does not require any installation as it only has to be placed on a desk
and connected to a PC through a USB cable.
The LDM 320W must be wall-mounted through the support plate. It is also connected to
a PC through a USB cable.
The USB cable can be positioned as follows:
by passing it behind the reader, through the partition by drilling a hole for this purpose, or
by passing it outside, through the notch at the bottom of the reader.
3.1.1. Installation
Remove the wall mount from the LDM 320W by unscrewing the four side screws.
Attach the plate to the wall via back-facing holes using four screws (not supplied).
Installation, Connection and Start-up LDM 320
6
