Five-pin contact connector.
J1 Pin No. Description
1 Vbus (red)
2 D- (white)
3 D+ (green)
4 GND (black)
5 GND (Cable shielding)
6.5. Extension Connector
Digital Outputs and Inputs can be controlled by the software: DMCUser. See user’s manual
of this software for details.
J4 is an extension connector available in-house and mainly used to manage inputs/outputs of
the 3V3 digital type.
J4 Pin No. Description
1 GND
2 INPUT Digital Input 3
3 INPUT Digital Input 1
4 OUTPUT Digital Output 1
5 INPUT Digital Input 2
6 OUTPUT Digital Output 2
7 INPUT Digital Input 4
8 OUTPUT Digital Output 3
9 3V3
10 OUTPUT Digital Output 4
11 5V
