J4 Pin No. Description
12 GND
13 5V
14 GND
15 INPUT Digital Input 5
16 Spare for ext. pwr sply
17 Spare for RX-LDM
18 Spare for RX-LDM
19 3V3
20 GND
21 Spare for analog input 1
22 GND
23 Spare for analog input 2
24 GND
25 Spare for external antenna (PWR4A)
26 Spare for external antenna (PWR4B)
